商品の詳細:
|
|
| 起源の場所: | 中国（本土） |
|---|---|
| ブランド名: | YT |
| モデル番号: | PC20 |
|
お支払配送条件:
|
|
| 最小注文数量: | 1pcs |
| 価格: | negotiable |
| パッケージの詳細: | エクスポートパッケージ |
| 受渡し時間: | 7〜30日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 10000 PCS/月 |
|
詳細情報 |
|||
| 材料: | 40Mn2か35MnBH鋼鉄 | 技術: | 鍛造材および熱処理 |
|---|---|---|---|
| 品質: | 熱処理 HRC 40-55 | 価格期間: | FOB/CFR/CIF/EXW |
| 色: | 黄色か黒い | 保証時間: | 12〜18ヶ月 |
| 状態: | 新しい | 重さ: | オプション |
| ハイライト: | Mid-Frequency Heat-Treatment Technology Track Chain Assembly,Self-Lubricated System Track Link Group,Precision Assembly Dimensions Excavator Undercarriage Spare Parts |
||
製品の説明
Utilizing sophisticated machining centers, including horizontal and vertical CNC technology, we perform precision operations like cutting, boring, tapping, and grinding to guarantee component quality and accuracy. This ensures precise assembly dimensions while extending component lifespan and minimizing hourly production expenses.
Track links are manufactured from 35 MNB forged special steel, reinforced with advanced structure technology and heat treatment processes. This combination delivers maximum strength and abrasion resistance. The integrated self-lubricated system significantly enhances track chain bearing service life.
| Suitable Model | P | A | B | C | E | F | H | K | L |
|---|---|---|---|---|---|---|---|---|---|
| EX30/EX35/PC20/PC30/PC35R | 101.6 | 55 | 55 | 22 | 10.5 | 35 | 76 | 63 | 26 |
| IHI30J | 101.6 | 64 | 64 | 22 | 10.5 | 44 | 85 | 63 | 26 |
| PC20 | 101.6 | 52 | 52 | 22 | 10.5 | 32 | 73 | 65 | 28 |
| YC35 | 101.6 | 55 | 55 | 22 | 12.5 | 35 | 77 | 70 | 30 |
| TM20 | 101.6 | 55 | 55 | 22 | 10.5 | 34 | 72 | 61 | 29.5 |
| PC40-7/SK45 | 135 | 93.8 | 63.8 | 46 | 12.5 | 40.4 | 87.4 | 65 | 30 |
| EX40/EX45 | 135 | 104 | 80 | 46 | 12.5 | 52 | 105 | 65 | 30 |
| PC60-6/PC75/SK60 | 154 | 89 | 73 | 57 | 14.5 | 45 | 104 | 74 | 33.5 |
| PC100-1/2/PC100-3/HD350 | 154 | 112.4 | 82.4 | 57 | 14.5 | 49.4 | 124.4 | 87 | 40 |
| EX60-1/2/3/5 | 154 | 90 | 90 | 55 | 14.5 | 56 | 127 | 80 | 38 |
The models above are for reference only. We can supply additional products to meet your requirements. Please contact us with your specific needs.
