ホーム 製品トラック キャリアのローラー50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage
50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage
50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage 50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage 50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage

50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage

商品の詳細:
起源の場所: 中国（本土）
ブランド名: YT
モデル番号: D50
お支払配送条件:
最小注文数量: 1個
価格: negotiable
パッケージの詳細: 標準のエクスポートパッケージ
受渡し時間: 7〜30日
支払条件: LC、T/T
供給の能力: 10000 PCS/月
接触

詳細情報
材料: 40Mn2、40MnB、50Mn 技術: 鍛造/キャスト
品質: 熱処理 HRC 40-55 色: 黄色か黒色か お客様の要求
保証時間: 12〜18ヶ月 仕上げる: スムーズ
出荷港: Xiamen トランスポートパッケージ: 顧客の要求として
ハイライト:

50Mn Steel Track Carrier Roller

,

40MnB Material Excavator Top Roller

,

Smooth Finish Undercarriage Support Roller

製品の説明

CATERPILLAR Construction Machinery Heavy Duty Undercarriage Spare Parts D50 Track Carrier Support Roller OEM Top Roller
What is a roller?
The roller is a crucial component of belt conveyors, available in steel and plastic varieties. It supports both the conveyor belt and material weight, accounting for 35% of total conveyor cost and generating over 70% of system resistance.
Our track and carrier rollers are manufactured from 40Mn2, 40MnB, or 50Mn steel, depending on application requirements. Through precision forging and heat treatment, we achieve surface hardness of HRC52-56 with hardened layer depth exceeding 7-10mm (HRC45) for exceptional durability.
Featuring high-quality floating seals and advanced lubrication systems, our rollers operate reliably in extreme temperatures from -45℃ to 120℃ with minimal maintenance requirements.
Carrier Rollers Excavator Advantages / Features
  • Specialized quench-tempering processes deliver superior mechanical properties, high strength, and excellent resistance to bending, breakage, and wear
  • Surface hardness of HRC 40-55 significantly reduces wear and extends service life
  • Precision engineering ensures proper installation, grouser compatibility, and heavy load capacity up to 50 tons
  • Consistent quality and cost-effectiveness for long-term performance
Main Dimensions of Installation
50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage 0
Brand Model A B D L M N O Remarks
Caterpillar E307 440 407 100 236 176 40 50 Models shown for reference only. Custom products available upon request.
E100B 480 450 130 270 216 46 60
E120B 480 450 130 270 216 46 60
E200B 540 500 160 300 270 60 65
E215 480 450 130 270 216 46 60
E312 480 450 130 270 216 46 60
E320 540 500 160 300 270 60 65
E330 680 636 214 373 350 60 85
Why Choose Us?
  • World-class manufacturing quality
  • Factory-direct pricing
  • Flexible payment terms (T/T, L/C, etc.)
  • Fast delivery within 30 days
  • Professional sales and quality control teams
  • Comprehensive after-sales support
Hot Sale Products
50Mn Steel Track Carrier Roller with 40MnB Material and Smooth Finish for Heavy Duty Excavator Undercarriage 1
FAQ
  • Are you a trader or manufacturer?
    We are an integrated business with manufacturing in Quanzhou and sales operations in Xiamen.
  • How to ensure part compatibility?
    Provide model/serial numbers, part markings, or detailed measurements.
  • Payment terms?
    Typically T/T or L/C, with other options negotiable.
  • Minimum order quantity?
    Normally $5000 USD, accepting both FCL and LCL shipments.
  • Delivery time?
    35-45 days for standard orders, 7-10 days for in-stock items.
  • Quality control?
    Comprehensive QC system monitoring all production stages.
